Do you like intensive cross-country? Then this is the wheel for you. Built around a 25mm wide rim, the Crossmax Carbon SL R 29 is made for modern racing and cross-country.
The full carbon rims guarantee lightning-fast acceleration and help you overcome technical climbs, with just the right amount of vertical flexibility to enable you to tackle every transition with precision and control. The carbon outer layer features our new UD² design, which gives it a distinctive visual identity and increases its durability.
The inner width (25 mm) allows all modern cross-country tyres to be fitted.
The spoking consists of 24 straight and narrow spokes for a perfect balance between lateral rigidity and vertical flexibility.
Mavic has designed an even lighter Infinity hub. In combination with the stiffness of the wheel and the specially chosen spoking, it maximises pedalling power for optimal power transfer.
Our Instant Drive 360 freewheel system, with its double ratchet mechanism, guarantees quick engagement. Sprint and accelerate more efficiently coming out of corners!
The rear hub is compatible with HG9, Micro Spline and SRAM XD freewheel bodies.
The Crossmax SL R is only available in 29" format and compatible with standard Boost axles (front 15x110 rear 12x148). The wheel comes complete with valves, spare spokes and accessories.
Tackle the most technical climbs with ease and save energy
Lightweight all-carbon wheels with UD² finish.
Precise handling and flexibility on technical cross-country terrain
Improved carbon fibre rim with 24 straight spokes. Lateral stiffness and flexible vertical feel.
Efficient power transfer
Lighter and stiffer Infinity hubs with reliable ID360 double ratchet freewheel body for instant acceleration.
Infinity hubs
Efficient power transfer thanks to optimised non-contact spoke lacing (no noise under load) and tension distribution. Front and rear spoke lengths are identical. Easy maintenance thanks to tool-free solution.
QRM Auto bearing adjustment technology
Quality Mavic Auto bearings. These cartridge bearings are naturally double sealed, with C3 internal clearance. The system automatically adjusts to ensure perfect rotation without play in the long term.
Instant Drive 360 freewheel system
The new Instant Drive 360 freewheel system is ultra-light and efficient. A non-contacting, oversized rubber seal minimises friction and a wide choice of adapters makes it compatible with a wide range of frames and axles.
Tubeless UST technology
Traction and control. Universal Tubeless Standard. Ready-to-ride tubeless system. The UST system improves traction, control and comfort while reducing inertia and the risk of punctures.
Hubs
Freewheel technology: Instant Drive 360
Bearing technology: QRM self-adjusting - sealed cartridge
Axle size: front 15x110 / rear 12x148
Axle material: aluminium
Body material: aluminium
Freewheel: Shimano MS / Sram XD MTB
Body design: INFINITY
Standard disc: 6 holes only or Center Lock
Rims
Tyre: UST Tubeless Ready - Use with Mavic tubeless rim tape
Braking: disc
Drilling: traditional (24 holes front/rear)
ETRTO size: 622x25TSS
Inner width: 25 mm
Profile: asymmetrical without hooks
Material: 100% carbon fibre with UD outer layer
Height: 25 mm
Delivered with
User guide
UST valve not mounted on the wheel
UST rim tape mounted on the wheel
Multi-function adjustment key with the rear wheel
2 spare spokes per wheel
Spokes
Material: steel
Spoking: cross 2 (front and rear)
Nipples: steel, ABS, black
Shape: straight, extra-flat, constricted, anti-rot (front and rear)
Intended use
ASTM category 3: cross country
Maximum weight supported by wheels: must not exceed 150 kg (including bike weight)
Maximum tyre size: width 64 mm - maximum pressure 2.45 Bar/36 PSI
Minimum tyre size: width 30 mm - maximum pressure 4.05 Bar/59 PSI
Compatibility
Freewheel body: convertible SHIMANO HG MTB steel
Front axle adapters: 15x110 convertible to 9x110
Front axle adapters: convertible to 15x31 mm with Torque Cap
Freewheel body: convertible SHIMANO HG MTB aluminium
Rear axle adapters: 12x148 convertible to 9x141
